DataVideo 4K Tracking PTZ Camera webcam 8.51 MP 2160 x 3840 pixels HDMI White

Description

Brand New 4K Auto Tracking PTZ Camera
Live productions depend on high performance cameras and camera controllers.
Datavideo is introducing the 4K50/60p auto tracking PTZ camera PTC-285 can be easily controlled via traditional RS-422 serial port or IP remote control via DVIP (Datavideo proprietary protocol) or Sony VISCA over IP. This brand new 4K camera series supports dual streaming output for A/V market application. You can easily stream to Facebook (RTMPS) YouTube and dvCloud.
Simultaneous Outputs
Connect your PTC-285 to multiple devices in your workflow for flexibility. All the outputs are active at the same time.
Quick Access to Camera's Auto Tracking
You will be allowed direct access to auto tracking via various external controllers such as the supplied RMC-1AT remote control and DVIP controllers (RMC-300A PTC View Assist etc.)
In addition to camera controllers you can also easily enable auto tracking on smart switchers which include KMU-200 SHOWCAST 100 etc as well as complete solution systems like ZR-1 Hybrid Video Production Solution.
Custom Auto Object Tracking
If you are filming multiple people you can designate a person for auto tracking. Once linked to the camera only the designated person will be tracked avoiding interferences such as the desks people coming back and forth large objects etc.
Smart PTZ Speed Adaptation
The integrated PID algorithm is able to detect the movement speed of the identified object and automatically adjust the camera's corresponding pan tilt and zoom speeds in such a way that the lens movement will be smooth avoiding common camera lens movement problems like jerky movements or unpredicted halts.
Talent Position: Center / Left Side / Right Side
The positioning of talent depends on the videographer's creativity and intent rather than strict rules. Different positions can convey various emotions messages or visual effects. A centered composition provides a sense of stability and balance suitable for scenes that require highlighting the main subject. Videographers may also place the talent on the left third or right third of the frame leaving adequate space in the foreground to showcase the talent's sight direction or potential future possibilities.
Quick Selection of Full Body / Half Body / Close-up
All of the PTC-285 camera series include RMC-1AT controller. User can quickly select full-body half-body and close up framing making it easy to change the shooting scene and framing requirements.
S-Shaped Speed Curve
The S-Shaped Speed Curve inspired by the smooth acceleration and deceleration of a lift is a pivotal feature that enhances the camera lens movement. Much like the elevator ride that starts and stops seamlessly the PTC-285 camera ensures your video captures maintain uninterrupted fluidity.
This innovative technology eliminates any jerky movements that might be discernible to the naked eye resulting in professional-quality visually pleasing content. The S-Shaped Speed Curve is your assurance that the camera's pan tilt and zoom functions will operate with precision and grace delivering an unparalleled visual experience for your audience. Experience the future of camera movement with the PTC-285.
Simply Enable Auto Tracking with Your IR Remote Control
RMC-1AT PTZ Controller: All you need is a remote control to set and control all four cameras and save the four presets.
Remote Control and Preview by Web User Interface
The web user interface provides preview pan-tilt-zoom control and configurations setting in IP mode.
PTZ View Assist: Control up to 4 Cameras
The camera control app is tailored for the Datavideo PTZ camera series. It can monitor the live streaming video from PTC-140 PTC-280 PTC-285 PTC-300 and PTC-305 series. The app can control up to 4 cameras simultaneously via DVIP you can intuitively set up and recall the presets and adjust white balance focus and IRIS.
The app is able to decode the live streaming via RTSP and SRT. Easily monitor the live streaming video and set up the parameters promptly in one application.
Low Noise in Low Light
Advanced 3D noise reduction technology is also used to further reduce the noise while ensuring image sharpness.
Multiple Simultaneous Video Outputs
Supports simultaneous HDMI 2.0 and IP output up to 2160p 50/60 and also 3G-SDI output up to 1080p60/50.
Multiple Network Protocol with Dual Stream Function
Support RTSP and RTMPS protocols easy to stream directly to two different CDN platforms and Datavideo dvCloud as well.
Compatible with Various Controller
Control real-time pan tilt and zoom camera movements with Datavideo Showcast 100 PTZ View Assist APP RMC-300A and RMC-180. With configurable preset positions supported.
RS-422 DVIP and Ethernet Camera Control
RS-422 and ethernet to use DVIP or VISCA over IP commands to integrate with larger control systems.
Compliant with the ONVIF Profile S Standard
The PTC-285 series cameras are compliant with the ONVIF Profile S standard ensuring seamless integration and interoperability in network video systems.
Power over Ethernet
The PTC-285 supports PoE for easy installation. No need to find local power outlets or hire an electrician to install outlets wherever you want to mount your camera. Simply run a single CAT6 cable to power your PTC-285.
Tally Light
Green and red lights tally to show the preview and program status for broadcast applications.
Wide 80 Field of View
PTC-285 provides a wide Field of View of 80 easily shooting all the scenes in the field.
Supports H.264/H.265 Video Compression
Support compression of resolution up to 3840x2160 with frame up to 59.94 60fps and the second channel 720x480 with 29.97fps compression. AAC MP3 and PCM audio compression also supported.
Dark or Light Body
The PTC-285 is available in dark gray or white to remain inconspicuous in permanent setups.
Build a Reliable SRT Live Streaming Workflow with All Datavideo Products
Datavideo's wide range of encoders cameras and hand-carry switchers are fully supported by SRT and dvCloud. Datavideo encoders and dvCloud provide reliable streams over unreliable networks.
By using a Datavideo encoder and dvCloud together you can utilize SRT (instead of RTMP) on the initial problematic connection or "First Mile." After your video stream reaches dvCloud you can depend on dvCloud's reliable high-bandwidth network to deliver the stream to your favorite destinations like Facebook and YouTube.
Remote Control from Anywhere in the World
Control the PTZ camera at the venue from anywhere in the world using the BB-1 KIT and dvCloud streaming service.
Single Operator Hybrid Event Solution Course
Explore our exclusive course on the Datavideo Academy website covering essential aspects of setting up a seamless hybrid production environment. Learn hardware connections software settings for key devices troubleshooting techniques and equipment operation. Gain the skills to navigate various scenarios in hybrid events from presentations to lectures. Equip yourself with the knowledge needed for successful setups using core components like the iCAST mini 4K touch screen switcher and PTC camera. Visit Datavideo Academy today for a comprehensive learning experience and master the art of hybrid event production.
Tutorial Videos Created Specifically for the PTC-285
Datavideo Academy is a comprehensive learning platform established by Datavideo Technology. As a professional Broadcast and AV equipment manufacturer Datavideo Technology is not only committed to providing quality products to users but also has the responsibility to help users learn to operate Datavideo products.
Through the Datavideo Academy platform users can easily master the operation of Datavideo products and experience the unique design of Datavideo products further creating a variety of applications and bringing a good user experience. Now a tutorial video for the PTC-285 is available at Datavideo Academy to help you get the best performance out of the product.
